- Cadre, fourche
Cadre: Haibike, SDURO Cross/Trekking, Aluminium 6061, Quick-release 5 x 135mm, Disc brake Post Mount
Fourche: SR Suntour, NEX E25-LO, Lockout, Steel spring, Travel= 63 mm, Steel steerer tube 1 1/8″, Quick release 100mm
- Moteur, batterie
Moteur: Bosch, Performance Line, 250 W, 65 Nm, 25 km/h
Batterie: Bosch, PowerPack, 500 Wh
Ecran: Bosch, Intuvia
- Groupe
Dérailleur arrière: Shimano, Deore M6000
Manette: Shimano, Deore M6000, Rapidfire, 10 speed
Plateau: Steel, 38 teeth
- Périphériques
Cintre: Haibike Components, TheBar +, 720 mm
Potence: Haibike Components, The Stem +, A-head
Tige de selle: Haibike Components, The Seatpost +, Patent, 31.6 mm, Aluminium
Selle: Haibike Components, TheSaddle
Eclairage avant: Trelock, Bike – i Veo LS230, 20 lm
Eclairage arrière: AXA, Blueline
Porte bagage: system carrier, 25.0 kg
Garde boue: SKS, Chromoplastics
Béquille: Ursus, Mooi, Rear stand
- Pneus, roues
Pneus: Schwalbe, Road Cruiser , 42-622, 28″ x 1.60″
Roues: Ryde, Zac421, bord creux, Aluminium
Poids: 23.9 kg
