- Cadre, fourche
Cadre: Haibike, SDURO Cross/Trekking, Aluminium 6061, Quick-release 5 x 135mm, Disc brake Post Mount
Fourche: SR Suntour, XCM ATB HLO, Lockout, Steel spring, Travel= 65 mm, Steel steerer tube 1 1/8″, Quick release 100mm
- Batterie, moteur
Batterie: Yamaha, InTube, 500 Wh
Moteur: Yamaha, PW-ST System, 250 W, 70 Nm, 25 km/h
Ecran: Yamaha, Side Switch, 1.7″ LCD, 7 functions
- Groupe
Dérailleur arrière: Shimano, Deore M6000
Manette: Shimano, Deore M6000, Rapidfire, 10 speed
Plateau: Steel, 38 teeth
Freins: Shimano, MT200, 180 mm, 2-piston disc brake
- Périphériques
Cintre: Haibike Components, TheBar +, 720 mm
Potence: Haibike Components, The Stem +, A-head
Tige de selle: Haibike Components, The Seatpost +, Patent, 31.6 mm, Aluminium
Selle: Haibike Components, TheSaddle
Eclairage arrière: AXA, Blueline
Porte bagage: system carrier, 25.0 kg
Garde boue: SKS, Chromoplastics
Béquille: Ursus, Mooi, Rear stand
- Roues, pneus
Roues: Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Pneus: Schwalbe, Super Moto X , 62-584, 27.5″ x 2.40″
Poids: 26.4 kg
